Volatile outgassing of H2O, O2 and THC is below detectable limits (by RGA and FID at room temperature)
Surface finish interior:
≤5 µin Ra
Total flow area:
Helium leak rating:
2 x 10-10 atm-cc/sec
1 x 10-9 atm-cc/sec
Maximum inlet pressure
52 bar (750 PSIG) @ 100°C
Maximum forward/reverse differential pressure
7 bar (100 PSID)
Maximum operating temperature
400°C @ 27.5 bar (400 PSIG)
Corrosive and reactive gases
50°C @ 52 bar (750 PSIG)
Greater than 99.9999999% (9 LRV) removal of all particles at 300 SLPM; greater than 99.9999% (6 LRV) removal of all particles at 750 SLPM (referenced at the most penetrating particle size)
See performance data
1 Particle cleanliness qualified following SEMASPEC Test Method for Particle Shedding (#93021511A-STD). 2 Verified at 100 SLPM for 1⁄4² gasket seal fitting (compatible with VCR® fitting). 3 Volatile cleanliness qualified following SEMASPEC Test Methods for: THC Contribution (#90120396B-STD), Moisture Contribution (#90120397B-STD), Oxygen Contribution (#90120398B-STD).
