2D Motion/Rocker Bags
Interested in 2D Motion/Rocker Bags?
Contact your Entegris account manager or
Top of page
Reference Materials
Applications
- Mammalian and plant culture cell lines with extended mixing times
- Growing NS0 and other cholesterol sensitive clones
Specifications
| Part Number | Bag Type | Size (L) | Dimensions | |
| A | B | |||
| FSC00730.02 | Standard 4-port | 10 | 330 mm (13.0") | 559 mm (22.0") |
| FSC00730.03 | Standard 4-port | 20 | 660 mm (26.0") | 559 mm (22.0") |
| FSC00730.04 | Standard 4-port | 50 | 724 mm (28.5") | 711 mm (28.0") |
| FSC00731.01 | Standard 5-port | 5 | 330 mm (13.0") | 559 mm (22.0") |
| FSC00731.02 | Standard 5-port | 10 | 330 mm (13.0") | 559 mm (22.0") |
| FSC00731.03 | Standard 5-port | 20 | 660 mm (26.0") | 559 mm (22.0") |
| FSC00731.04 | Standard 5-port | 23 | 381 mm (15.0") | 711 mm (28.0") |
| FSC00731.05 | Standard 5-port | 50 | 724 mm (28.5") | 711 mm (28.0") |
| FSC00732.02 | Standard 7-port | 10 | 330 mm (13.0") | 559 mm (22.0") |
| FSC00732.03 | Standard 7-port | 20 | 660 mm (26.0") | 559 mm (22.0") |
| FSC00732.05 | Standard 7-port | 50 | 724 mm (28.5") | 711 mm (28.0") |
| FSC00390.00 | Motion/rocker | 1 | 260 mm (10.38") | 552 mm (21.75") |
| FSC00390.01 | Motion/rocker | 2 | 260 mm (10.38") | 552 mm (21.75") |
| FSC00405.01 | Motion/rocker | 10 | 330 mm (13.0") | 381 mm (15.0") |
| Sizes: | 10 L, 20 L, 50 L 5 L, 10 L, 20 L, 23 L, 50 L 10 L, 20 L, 50 L |
Standard 4-port (budget) bag Standard 5-port bag Standard 7-port bag |
| Air outlet: | 0.2 µm filter, clamp, check valve, 1/4" x 3/8" x 1.75" silicone tubing | |
| Air inlet: | 0.2 µm filter, clamp, 1/4" x 3/8" x 1.75" silicone tubing | |
| Evac/inoc port: | Clamp, female Luer lock, 1/8" x 1/4" x 40" C-flex tubing | |
| Clamp, female CPC, 1/8" x 1/4" x 40" C-flex tubing | 5-port and 7-port bags only | |
| Injection site: | Needless, clamp, 1/4" x 3/8" x 1.75" silicone tubing | |
| Spare port: | Clamp, female Luer lock, 1/4" x 3/8" x 1.75" silicone tubing | 7-port bag only |
| Powder port: | 1" threaded cap | 7-port bag only |
| Bag film: | Flex 200, Flex 400 | |
| Various port options are avaiable. Contact Entegris with your specifications. | ||
