Azora™ Photochemical Bulk Filter
Specify Your Part
Part Number:
Interested in an Entegris Product?
To discuss your specific needs, contact your local Entegris representative.
Don't have an Entegris representative?
Contact Us
Request a Quote
Quote Requested
Thank you for requesting a quote. Someone from Entegris will contact you shortly.
Your quote number is {0}.
Top of page
Reference Materials
CAD
CAD drawings may be available for this product. Please use the Part Selector to select a part number to see if they are available.
Applications
- Advanced photochemical and raw materials
- Advanced photosolvents
Specifications
| Length | A | B |
| 10" | 262.3 mm (10.33") | 245.0 mm (9.65") |
| 20" | 506.6 mm (19.94") | 489.2 mm (19.26") |
| Azora Gen 1 bulk cartridge filters | Azora Gen 2 bulk cartridge filters | Azora Gen 1 disposable filters | Azora Gen 2 disposable filters | ||
| Materials of construction | Membrane | Polyimide | |||
| Supports, core, sleeve, shell/housing | High density polyethylene (HDPE) | ||||
| O-ring (222) | Encapsulated FKM (E-FKM) | – | |||
| Connections | Code 0 | 1/4" comporession fitting | |||
| Membrane area | 10": 1.01 m² (10.9 ft²) 20": 2.09 m² (21.7 ft²) |
10": 1.31 m² (14.1 ft²) 20": 2.62 m² (28.2 ft²) |
0.22 m² (2.4 ft²) | ||
| Hold-up volume | – | 160 cc | |||
| Maximum operating conditions | Maximum inlet pressure | – | 0.34 MPa (3.4 bar, 50 psi) @ 25°C (77°F) | ||
| Maximum forward/reverse differential pressure | 0.24 MPa (2.4 bar; 50 psi) @ 25°C (77°F) | 0.27 MPa (2.7 bar; 39 psi) @ 25°C (77°F) | |||
| Maximum temperature | 60°C (140°F) | ||||
| Flow performance | Typical device pressure drop | 10": 1.9 L/min @ 0.02 MPa 20": 3.6 L/min @ 0.02 MPa |
10": 2.2 L/min @ 0.04 MPa 20": 4.4 L/min @ 0.04 MPa |
1.4 L/min @ 0.06 MPa | 0.7 L/min @ 0.06 MPa |
| Format | Length | 10", 20" | – | ||
| Diameter | 70 mm | – | |||
Successfully Opted for software Updates
Part Numbers
| Part Number | Product Type | Clean | Format | Membrane |
|---|---|---|---|---|
| AZ0101MTU3 | Cartridge filter | Ultraclean | 10", 70 mm | Azora Gen 1 |
| AZ0102MTU3 | Cartridge filter | Ultraclean | 20", 70 mm | Azora Gen 1 |
| AZ010S2S1U3 | Disposable filter | Ultraclean | Short | Azora Gen 1 |
| AZ0201MTU3 | Cartridge filter | Ultraclean | 10", 70 mm | Azora Gen 2 |
| AZ0202MTU3 | Cartridge filter | Ultraclean | 20", 70 mm | Azora Gen 2 |
| AZ020S2S1U3 | Disposable filter | Ultraclean | Short | Azora Gen 2 |
