198/192 Series 200 mm Wafer Transport Carriers

Download Image

Designed for advanced wafer transport, our 200 mm open-side wall wafer carriers offer dramatic performance benefits over traditional low- and midrange wafer carriers.

The wafer is in a predictable location, enabling precise wafer access
Reliable equipment operation on process tools and automated materials handling systems
Secures and protects wafer against contamination and damage

Read More Read Less

Specify Your Part

End Wall Handle Type

Color

RFID

Materials

"H" Bar End Flange

Part Number:

Interested in an Entegris Product?

To discuss your specific needs, contact your local Entegris representative.

Don't have an Entegris representative?

Request a Quote

Please fill out the form below and someone will contact you shortly.

* Required

First Name:

Please enter a first name

Last Name:

Please enter a last name

Country:

Please select a country/region

Email Address:

Please enter a valid email

Phone Number:

Please enter a valid phone number.

Company:

Please enter your company.

Company Address

You are required to accept the Captcha.

An error occurred while submitting your quote request. Please try again.

Cancel

Quote Requested

Thank you for requesting a quote. Someone from Entegris will contact you shortly.

Your quote number is {0}.

Top of page

CAD CAD Files

CAD drawings may be available for this product. Please use the Part Selector to select a part number to see if they are available.

Go to Part Selector

Applications 198/192 Series 200 mm Wafer Transport Carriers Applications

198/192 series 200 mm wafer transport carriers are ideal for:

In-fab transport
Process tool interface
Storage of fab wafers

Specifications

Drawings

D1 dimension	25.4 mm (1.00"), dependent on cassette
Pocket spacing	6.4 mm (0.25"), dependent on cassette
Pocket flat	1.7 mm (0.07") dependent on cassette

Product Specifications

Wafer capacity	25
Pins and holes	on top rail
Locating track notches	at center of the 13th pocket
Side walls	Open
Compatible storage boxes	E99, E210, HA200

Material Specifications

STAT-PRO 9000	Next Generation advanced wafer transport carrier material
	Static dissipative blend of Carbon Nanotube (CNT) enhanced polyetheretherketone (PEEK™) carbon compound
	Temperature limits:	120°C (248°F) continuous use
		340°C (644°F) wafer insertion
STAT-PRO 3000	Advanced wafer transport carrier material
	Static dissipative blend of PEEK and carbon fiber
	Temperature limits:	120°C (248°F) continuous use
		340°C (644°F) wafer insertion
STAT-PRO 100	Wafer transport carrier material
	Static dissipative blend of polypropylene (PP) and carbon powder
	Temperature limits:	55°C (131°F) continuous use
		70°C (158°F) wafer insertion
FluoroSentry^®	Wafer transport carrier material
	Advanced blend of polybutyleneterephthalate (PBT) and carbon fiber
	Temperature limits:	55°C (131°F) continuous use
		95°C (203°F) wafer insertion
Blue Polypropylene	Wafer transport carrier material
	PP with added colorant
	Temperature limits:	55°C (131°F) continuous use
		70°C (158°F) wafer insertion

Successfully Opted for software Updates

Reference Materials Product Documentation

Published Aug 9, 2022 Data Sheet 198/192 Series 200 mm Wafer Transport Carriers

734.5 kB

Published Aug 9, 2022 Data Sheet 198/192 Series 200 mm Wafer Transport Carriers - A4

734.5 kB

Videos

Cassette Molded Options

Carrier ID Option

Part Numbers

198/192 Series 200 mm Wafer Transport Carriers Part Numbers

Part Number	End Wall Handle Type	Color	RFID	Materials	"H" Bar End Flange
FA192-80MNS-7902	Standard, high position	Black	No	FluoroSentry® carbon fiber PBT	No
FA192-80MNSM-7902	Standard, high position	Black	Yes	FluoroSentry® carbon fiber PBT	No
K198-80M-97C02	Standard, high position	Black	No	STAT-PRO® 9000 CNT PEEK	No
K198-80MB-97C02	Standard, high position	Black	No	STAT-PRO® 9000 CNT PEEK	Yes
KA198-80M-47C02	Standard, high position	Black	No	STAT-PRO® 3000 carbon fiber PEEK	No
KA198-80M-47C05	Standard, high position	Green	No	STAT-PRO® 3000 carbon fiber PEEK	No
KA198-80MB-47C02	Standard, high position	Black	No	STAT-PRO® 3000 carbon fiber PEEK	Yes
KA198-80MRM-47C02	Standard, high position	Black	Yes	STAT-PRO® 3000 carbon fiber PEEK	No
PA192-80M-0603	Standard, high position	Blue	No	Polypropylene	No
PA192-80M-0604	Standard, high position	Red	No	Polypropylene	No
PA192-80M-0605	Standard, high position	Green	No	Polypropylene	No
PA192-80M-0607	Standard, high position	Yellow	No	Polypropylene	No
PA192-80M-0609	Standard, high position	Orange	No	Polypropylene	No
PA192-80M-0615	Standard, high position	Natural	No	Polypropylene	No
